Biến đổi nhiệt độ 2 dây APAQ C130
Type: Head mounted
Input: Pt100, Pt1000
Type of transmitter: Digital
Output: 4-20 mA
Measuring range: –200…+850 °C / -328…+1562 °F
Typical accuracy: Max. ±0,15 K or ±0,15 % of span
Configuration: App INOR Connect*
Wireless communication: NFC®
Biến đổi nhiệt độ 2 dây APAQ R130
Type: Rail mounted
Input: Pt100, Pt1000
Type of transmitter: Digital
Output: 4-20 mA
Measuring range: –200…+850 °C / -328…+1562 °F
Typical accuracy: Max. ±0,15 K or ±0,15 % of span
Configuration: App INOR Connect*
Wireless communication: NFC®
Biến đổi nhiệt độ 2 dây IPAQ C202
Type: Head mounted
Input: RTD
Input RTD: Pt100
Type of transmitter: Digital
Output: 4-20 mA
Isolation: Unisolated
Measuring channels: 1 channel
Sensor connection: 3-wire connection
Biến đổi nhiệt độ 2 dây IPAQ C330
Type: Head-mounted
Input: RTD, TC, mV, ohm
Input RTD: Pt100, Pt1000, Ni100, Ni120, Ni1000, Cu10
Input thermocouple: Type B, C, D, E, J, K, N, R, S, T
Output: 4-20 mA
Galvanic isolation: 1500 VAC
Measuring channels: 1 channel
Sensor connection: 2-, 3-, 4-wire connection
Power supply: IPAQ-C330: 8 to 36 VDC/ IPAQ-C330X: 8 to 30 VDC
Biến đổi nhiệt độ 2 dây IPAQ C530
Type: Head-mounted
Input: RTD, TC, mV, ohm
Input RTD: Pt100, Pt1000, Ni100, Ni120, Ni1000, Cu10
Input thermocouple: Type B, C, D, E, J, K, N, R, S, T
Output: 4-20 mA, HART protocol
Galvanic isolation: 1500 VAC
Measuring channels: 1 channel
Sensor connection: 2-, 3-, 4-wire connection
Biến đổi nhiệt độ 2 dây IPAQ R202
Type: Rail mounted
Input RTD: Pt100
Type of transmitter: Digital
Output: 4-20 mA
Isolation: Unisolated
Measuring channels: 1 channel
Sensor connection: 3-wire connection
Power Supply: Standard version: 6 to 32 VDC
Typical accuracy: Max. ±0.1K or ±0,1 % of span
Biến đổi nhiệt độ 2 dây IPAQ R330
Type: Rail-mounted
Input: RTD, TC, mV, ohm
Input RTD: Pt100, Pt1000, Ni100, Ni120, Ni1000, Cu10
Input thermocouple: Type B, C, D, E, J, K, N, R, S, T
Output: 4-20 mA
Galvanic isolation: 1500 VAC
Measuring channels: 1 channel
Sensor connection: 2-, 3-, 4-wire connection
Biến đổi nhiệt độ 2 dây IPAQ-21
Type: Rail-mounted
Input: RTD, Thermocouple, Universal
Input RTD: Pt100, Pt1000, Ni100, Ni120, Ni1000, Cu10
Input Thermocouple: Type B, C, E, J, K, L, N, R, S, T, U
Output: 4-20 mA
Isolation: Isolated
Measuring channels: 1 channel
Sensor connection: 3-, 4-wire connection
Approvals: ATEX
Typical accuracy: ±0.1 % of span
Biến đổi nhiệt độ 2 dây IPAQ R520
Type: Rail-mounted
Input: RTD; Thermocouple; Universal
Input RTD: Pt10, Pt50, Pt100, Pt200, Pt500, Pt1000, Ni100, Ni120, Ni1000, Cu10
Input Thermocouple: Type B, C, D, E, J, K, N, R, S, T
Output: 4-20 mA; HART®
Isolation: Isolated
Measuring channels: 2 channels
Sensor connection: 2-, 3-, 4-wire connection
Approvals: ATEX, IECEx, SIL2
Biến đổi nhiệt độ 2 dây IPAQ R530
Type: Rail-mounted
Input: RTD, TC, mV, ohm
Input RTD: Pt100, Pt1000, Ni100, Ni120, Ni1000, Cu10
Input thermocouple: Type B, C, D, E, J, K, N, R, S, T
Output: 4-20 mA, HART protocol
Galvanic isolation: 1500 VAC
Measuring channels: 1 channel
Sensor connection: 2-, 3-, 4-wire connection
Biến đổi nhiệt độ 2 dây MinIPAQ-L
Type: Rail-mounted
Input: RTD; Thermocouple
Input RTD: Pt100, Pt1000, Ni100, Ni120, Ni1000, Cu10
Input Thermocouple: Type B, C, E, J, K, L, N, R, S, T, U
Output: 4-20 mA
Isolation: Unisolated
Measuring channels: 1 channel
Sensor connection: 3-, 4-wire connection
Typical accuracy: 0.15% of span
Biến đổi nhiệt độ 2 dây IPAQ-Lplus
Type: Rail-mounted
Input: RTD; Thermocouple; Universal
Input: Pt100, Pt1000, Ni100, Ni120, Ni1000, Cu10
Input Thermocouple: Type B, C, E, J, K, L, N, R, S, T, U
Output: 4-20 mA
Isolation: Isolated
Measuring channels: 1 channel
Sensor connection: 3-, 4-wire connection
Typical accuracy: 0.05% of span
Biến đổi nhiệt độ 2 dây IPAQ-Hplus
Type: Head-mounted
Input: RTD; Thermocouple; Universal
Input RTD: Pt100, Pt1000, Ni100, Ni120, Ni1000, Cu10
Input Thermocouple: Type B, C, E, J, K, L, N, R, S, T, U
Output: 4-20 mA
Isolation: Isolated
Measuring channels: 1 channel
Input connection: 3-, 4-wire connection
Typical accuracy: 0.05% of span
Biến đổi nhiệt độ 3 dây APAQ-3HPT
Type: Head-mounted
Input RTD: Pt100, Pt1000
Output: 0-10 V
Isolation: Unisolated
Measuring channels: 1 channel
Input connections: 3-wire connection
Power supply: 15 to 30 VDC
Biến đổi nhiệt độ 3 dây APAQ-3LPT
Type: Rail-mounted
Input RTD: Pt100, Pt1000
Output: 0-10 V
Isolation : Unisolated
Measuring channels: 1 channel
Sensor connection: 3-wire connection
Power supply: 15 to 30 VDC
Typical accuracy: 0.15% of span
